Single Auger Powder Filling Machine

Product Details

Single Auger Powder Filling Machine

Single Auger Powder Filling Machine by Shivoham Pharma Machines LLP

Our Single Auger Powder Filling Machine is a highly efficient and precise equipment designed for accurately filling powders into containers, bottles, jars, or pouches. Ideal for industries such as pharmaceuticals, food, spices, chemicals, and cosmetics, this machine ensures consistent dosage and high productivity in a compact design.

Constructed from high-quality stainless steel, the machine guarantees durability, corrosion resistance, and easy sanitation. Its innovative auger mechanism precisely measures and dispenses powders, making it suitable for filling free-flowing powders and granules. The filling volume can be easily adjusted through a user-friendly control panel, allowing for quick changeovers between different container sizes and product specifications.

The system features a hopper for powder storage, which is designed for easy filling and cleaning. The auger screw moves the powder smoothly and precisely into containers, minimizing wastage and ensuring uniform filling. The machine can be integrated with automatic or semi-automatic filling systems, offering flexibility based on production needs.

Designed for ease of operation and maintenance, it includes features such as simple disassembly for cleaning, safety interlocks, and overload protection. Its compact footprint makes it suitable for various production environments with limited space.

Overall, the Single Auger Powder Filling Machine offers a reliable, accurate, and cost-effective solution for powder filling requirements, helping manufacturers improve efficiency, reduce wastage, and maintain consistent product quality.

Standard as well as Optional Servo Driven Filling Head

No Bottle - No Fill System

All contact parts made of SS316 and Nylon/HDPE material with easy removal system for Cleaning

Machine construction in SS304 material

C. Variable Frequency Drive Speed Control

Built in Turn Tables with Separate Drive for speed control

Low Air - Machine Stop System

Heavy Duty Mounting system for Powder Wheel for Trouble Free long-term operations

Model No.: AEPF 1
Container Diameter 25mm to 85mm*
Container Height 100mm* Maximum
Filling Range 5gms. To 60gms. In Single Dose System
Accuracy +/- 2 to 3% Depending upon the Powder, under the controlled level of Humidity
Humidity Below 30% Rh required on machine to be arrange by customer
Electrical 415VAC 3Phase and 220 VAC Single Phase Power Supply (50 Hz) with A.C. Drive
Power 2.0 H.P.
Conveyor Height 815-940 mm adjustable
Overall Dimensions 1810 mm (L) x 905 mm (W) x 1900 mm
Production Output Max. 30 bottles per min

* Specification can be changed as per customers’ requirements
